Intel PRO/1000T PCI-64 Network Adapter 1 x RJ-45 10/100/1000Base-T

€15.00
€13.50 Save 10%

Intel PRO/1000T PCI-64 Network Adapter 1 x RJ-45 10/100/1000Base-T NIC Hot-Plug

Quantity

  Security policy

My Playhouse is not in the market, of selling Your data to anyone.

  Delivery policy

Shipping out of Denmark is expensive. Be advised that My PlayHouse, is selling as a private person.

  Return policy

Used stuff, privat rules apply. I really rather not not have to mess with returns.

Intel PRO/1000T Network Adapter PCI 1 x RJ-45 10/100/1000Base-T - PWLA8490T

Description:

This is a Compaq NC7131 64/66 PCI, 10/100/100-T Gigabit Server Adapter, it is part number 223773-001 and spare part number 161665-001. This is a USED part, it has been pulled and tested from a working machine. It is sold exactly as shown and does not include any additional parts, drivers or software.



 Specifications:

  • Bus interface: PCI 64-bit / 66MHz, compatible with 64-bit / 33MHz or 32-bit, 33-MHz Bus Master DMA
  • Compliance: IEEE 802.3i, 802.3u, 802.3x, 802.3ab, 802.3ad (static configuration mode only), 802.1p, and 802.1Q
  • Power requirements: 1600mA@+5V typical
  • Certifications: BSMI Class A, FCC Class B, VCCI Class B, CISPR 22 Class B, EN60950, EN55022 Class B, EN55024, ICES-003 Class B, UL
  • Data Transfer: 32-bit bus-master PCI, 10 or 100Mb/s, Auto negotiating
  • Connector: One RJ-45
  • Communication processor: Intel 82543GC chipset
  • Supported cabling: CATegory 5 or higher UTP (4 pair), Up to 100 meters (328 feet)
  • Standard Features:
    • Auto-negotiating 10/100/1000 RJ-45 port delivers Gigabit Ethernet over copper cabling
    • 64-bit/66MHz PCI, compatible with 64-bit/33MHz or 32-bit/33MHz Bus Master DMA
    • Support for IEEE standards 802.3ab, 802.3u, 802.3x, 802.1p, and 802.1Q
    • Support for IEEE 802.3ad Link Aggregation (static configuration mode only)
    • Support for Fast EtherChannel and Gigabit EtherChannel
    • PCI Hot Plug compliant
    • LED indicators for activity, link integrity, and speed
    • 64-bit addressing for systems with more than 4GB of physical memory
    • Full- and half-duplex operation
    • Adaptive Load Balancing (ALB)
    • Network Fault Tolerance (NFT)
  • Operating system support:
    •  Windows 2000
    • Windows NT 4.0
    • Novell NetWare 4.x, 5.x Server
    • SCO UnixWare 7.x
    • SCO OpenServer 5.x
    • Linux Red Hat 7.x
    • MS-DOS Client for unattended installation
  • Operating temperature: 0° to 55°C / 32° to 131°F
  • Shipping temperature: -65° to 85°C / -85° to 185°F
  • Operating humidity: 10% to 90% (noncondensing)



Compatible with Server Models: 8000, 8500, CL380, DL320 G1, DL360 G1, DL380 G1/G2, DL580 G1, DL590, DL760 G1, ML330 G1, ML330e, ML350 G1/G2, ML370 G1/G2, ML530 G1, ML570 G1, ML750
