Intel PRO/1000T PCI-64 Network Adapter 1 x RJ-45 10/100/1000Base-T
Intel PRO/1000T PCI-64 Network Adapter 1 x RJ-45 10/100/1000Base-T NIC Hot-Plug
My Playhouse is not in the market, of selling Your data to anyone.
Shipping out of Denmark is expensive. Be advised that My PlayHouse, is selling as a private person.
Used stuff, privat rules apply. I really rather not not have to mess with returns.
Intel PRO/1000T Network Adapter PCI 1 x RJ-45 10/100/1000Base-T - PWLA8490T
Description:
This is a Compaq NC7131 64/66 PCI, 10/100/100-T Gigabit Server Adapter, it is part number 223773-001 and spare part number 161665-001. This is a USED part, it has been pulled and tested from a working machine. It is sold exactly as shown and does not include any additional parts, drivers or software.
Specifications:
- Bus interface: PCI 64-bit / 66MHz, compatible with 64-bit / 33MHz or 32-bit, 33-MHz Bus Master DMA
- Compliance: IEEE 802.3i, 802.3u, 802.3x, 802.3ab, 802.3ad (static configuration mode only), 802.1p, and 802.1Q
- Power requirements: 1600mA@+5V typical
- Certifications: BSMI Class A, FCC Class B, VCCI Class B, CISPR 22 Class B, EN60950, EN55022 Class B, EN55024, ICES-003 Class B, UL
- Data Transfer: 32-bit bus-master PCI, 10 or 100Mb/s, Auto negotiating
- Connector: One RJ-45
- Communication processor: Intel 82543GC chipset
- Supported cabling: CATegory 5 or higher UTP (4 pair), Up to 100 meters (328 feet)
- Standard Features:
- Auto-negotiating 10/100/1000 RJ-45 port delivers Gigabit Ethernet over copper cabling
- 64-bit/66MHz PCI, compatible with 64-bit/33MHz or 32-bit/33MHz Bus Master DMA
- Support for IEEE standards 802.3ab, 802.3u, 802.3x, 802.1p, and 802.1Q
- Support for IEEE 802.3ad Link Aggregation (static configuration mode only)
- Support for Fast EtherChannel and Gigabit EtherChannel
- PCI Hot Plug compliant
- LED indicators for activity, link integrity, and speed
- 64-bit addressing for systems with more than 4GB of physical memory
- Full- and half-duplex operation
- Adaptive Load Balancing (ALB)
- Network Fault Tolerance (NFT)
- Operating system support:
- Windows 2000
- Windows NT 4.0
- Novell NetWare 4.x, 5.x Server
- SCO UnixWare 7.x
- SCO OpenServer 5.x
- Linux Red Hat 7.x
- MS-DOS Client for unattended installation
- Operating temperature: 0° to 55°C / 32° to 131°F
- Shipping temperature: -65° to 85°C / -85° to 185°F
- Operating humidity: 10% to 90% (noncondensing)
Compatible with Server Models: 8000, 8500, CL380, DL320 G1, DL360 G1, DL380 G1/G2, DL580 G1, DL590, DL760 G1, ML330 G1, ML330e, ML350 G1/G2, ML370 G1/G2, ML530 G1, ML570 G1, ML750
